Media Finish: Gloss
Media Width: 54" (Special Order)
Roll Length: 45m (Full Roll)
Log in to purchase


Ultracurve H1 is a 153 micron flexible white polymeric vinyl film, backed with an aggressive pressure sensitive acrylic adhesive system, specifically engineered to adhere to sport helmets. With broad HSE/LSE plastic adhesion and clean removability, Ultracurve H1 is a winning helmet decal choice for Football, Baseball, Lacrosse, Hockey, Motocross, and more!



Recommended Uses

Substance Incorporated recommends the following end uses for Ultracurve H1:
Decals for football, baseball, lacrosse, hockey, motorsports, and industrial helmets. Market leading decals for sport helmets that require strong adhesion.
Decals applied to HSE/LSE plastics that require clean long-term removability. Applications that require aggressive adhesion with low shrinkage characteristics.



Ultracurve H1
Material 153 micron Polymeric Calendered Vinyl

Colour Opaque White

Tensile Strength 68N/25mm

Adhesive Clear Solvent-Based Pressure Sensitive Acrylic
Adhesive Thickness 0.056mm +/- 10%
Peel Adhesion 27N/25mm from Stainless Steel
Liner 90LB Natural Brown PE Coated Layflat Paper

Liner Release 32 grams/25mm

Dimensional Stability 0.5 mm
Application Temp. 0°C to 27°C recommended, test prior to specific application
Temperature Range -53°C to 104°C
Shelf Life 2 years when stored at 21°C and 50% relative humidity
Print Compatability Solvent, Eco-Solvent, Latex, UV, and Thermal Transfer Inks
Graphic Life Outdoor durability up to 7 years (unprinted), permanent
Chemical Resistence Resists mild acids, mild akalis, solvents, and salts. Excellent resistance to water, including immersion.



Before applying an overlaminate, allow 24 hours for print to dry. Application surface must be free of dust, dirt, debris, grease, and other contaminants. We highly recommend cleaning the installation surface with isopropyl alcohol prior to application. Dry installation is recommended. Please test any application fluid prior to use. Mild heat may be used during installation to help Ultracurve H1 conform to irregular surfaces.
